Model |
LSX II |
Drive units |
Uni-Q driver array: HF: 19mm (0.75in.) aluminium dome LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone |
Frequency range (-6dB) measured at 85dB/1m |
49Hz – 47kHz *Depends on EQ settings |
Frequency response (±3dB) measured at 85dB/1m |
54Hz – 28kHz *Depends on EQ settings |
Amplifier output power (per speaker) |
LF: 70W HF: 30W |
Amplifier class (per speaker) |
LF: Class D HF: Class D |
Max SPL measured at 1m |
102dB |
Wireless streaming features |
AirPlay 2 Google Chromecast Roon Ready# UPnP Compatible Bluetooth 4.2 |
Streaming services |
Spotify via Spotify Connect Tidal via Tidal Connect Amazon Music Qobuz Deezer QQ Music via QPlay Internet Radio Podcast *Depends on services availability in different countries |
Source resolution |
Network up to 384kHz/24bit Optical up to 96kHz/24bit USB Type C up to 192kHz/24bit HDMI up to 1.411Mbps PCM *Depends on source resolution |
Interspeaker connection |
Wireless: all sources resampled to 48kHz/24bit PCM Wired: all sources resampled to 96kHz/24bit PCM |
Supported format (network) |
MQA, DSD, FLAC, WAV, AIFF, ALAC, AAC, WMA, MP3, M4A, LPCM and Ogg Vorbis |
Dimensions (HWD per speaker) |
240 × 155 × 180 mm (9.5 × 6.1 × 7.1 in.) |
Weight (per set) |
7.2kg (15.6lbs) |
Power input |
100 – 240VAC 50/60Hz |
Power consumption |
200W (operating power) <2.0W (standby power) |
Inputs (primary speaker) |
HDMI ARC TOSLINK Optical USB Type C Analogue 3.5mm Auxiliary RJ45 Ethernet (network) RJ45 Ethernet (interspeaker) |
Inputs (secondary speaker) |
RJ45 Ethernet (interspeaker) |
Output |
RCA Subwoofer output |
Wi-Fi network standard |
IEEE 802.11a/b/g/n/ac IPv4, IPv6 |
Wi-Fi network frequency band |
Dual-band 2.4 GHz / 5 GHz |
