Naim 555 PS
The ultra-low noise 555 PS was originally designed to power the CD555 CD player but is also backwards- compatible with the CDS3 and CDX2 players.
It can further be used to enhance the performance of the Naim HDX hard disk player and Naim DAC.
Within the supply''s low resonance case with isolating feet there is a transformer that is 40 per cent larger than that in the XPS with five secondary windings outputting seven regulated power supplies including a separate one for the CD555 clock circuitry.
The 555 PS also has separate dedicated analogue and digital output sockets (Burndy) to minimise high frequency noise modulation of the analogue supplies.
Naim Discrete Regulator.
The 555 PS was updated in 2012 as a result of a two year project to develop a new discrete regulator (DR) for Naim power supplies.
The new Naim DR now features, alongside improvements to the transformer mounting, wire gauge, wire routing, mechanical decoupling, internal layout and reservoir capacitors.
These improvements, developed through intensive listening tests, significantly raise performance and make music even more communicative and enjoyable.
Power Outputs 22V, 10V, 12V, 2 x 15V
Mains Supply 100V, 115V, 230V; 50 or 60Hz
Dimensions 87 x 432 x 314mm (H x W x D)
Front Brushed and black anodised
Case Brushed and black anodised
