| Date of Introduction |
August 2004 |
| Product Type |
Multi-channel AV pre-amplifier & system controller |
| Dimensions (HxWxD) |
80 x 381 x 368mm |
| Weight |
5kg |
| Control Interfaces |
Remote control IR receiver
RC5 input and output RCA connector
KNEKT main system input
KNEKT RCU socket
4x KNEKT room outputs
2x IR flasher outputs
2x Independent RS232 ports
Ethernet terminal (for future applications)
4x Independent +12V trigger outputs
1x PS2 keyboard interface (front panel)
6 button keypad interface
128 x 32 front panel VFD graphical monochromatic display
|
| Digital Audio Inputs |
3x TOSLINK™ inputs
3x SPDIF™ RCA socket inputs
1x TOSLINK™ input (front panel)
(supporting 44.1 kHz / 48kHz / 88.2kHz / 96kHz sample rates)
|
| Analogue Audio Inputs |
KNEKT main system input
5.1 audio input from 6 pairs of RCA sockets
1 pair of RCA socket inputs (front panel)
|
| Analogue Video Inputs |
12x Composite / 4x Component configurable RCA socket inputs (one with H&V syncs)
4x S-video mini-DIN socket inputs
2x SCART input/output sockets
1x Composite RCA socket input (front panel)
1x S-video mini-DIN socket input (front panel)
|
| Digital Audio Outputs |
1x TOSLINK™ record output
1x SPDIF™ RCA socket record output
1x TOSLINK™ record output (front panel)
(supporting 44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz sample rates)
|
| Analogue Audio Outputs |
7.1 RCA socket listen outputs
1 pair of RCA socket record outputs
1x 1/4" Stereo headphone socket (front panel)
4x KNEKT room outputs (linked to record path)
|
| Analogue Video Outputs |
2x Composite RCA socket watch outputs
1x Composite RCA socket record output
1x S-video Mini-DIN socket watch output
1x S-video Mini-DIN socket record output
1x Component video RCA socket watch output (with optional H&V syncs)
|
| Front Panel Interfaces |
1x TOSLINK™ input
1x TOSLINK™ record output
1x pair of RCA socket inputs
1x Composite RCA socket input
1x S-video mini-DIN socket input
|
| Audio Decoding |
Dolby Digital 5.1, Dolby Digital EX, Dolby Headphone, Dolby Pro Logic II Movie & Music mode, AAC Surround, MPEG 2, DTS Surround, DTS 96/24, DTS CD, DTS ES Matrix & Discrete, Stereo + Sub Analogue/Digital Bass Redirect, 3 Stereo Analogue/Digital Downmix, Phantom Analogue/Digital Downmix, LoRo Analogue 5.1 to Stereo Downmix, LtRt Digital Downmix, LIMBIK Party, adjustable lip sync delay.
|
| Video Decoding |
Automatic PAL and NTSC detection
Automatic interlace / progressive scan detection
|
| Video Formats |
Composite, S-video, YPrPb, RGB, RGBHV, HDV (no OSG) |
| User Interface |
Menu driven OSG Down/up-loadable configurations via RS232 terminal |
| Power Supply |
Switching power supply with auto-ranging (90V a.c. to 240V a.c. / 50-60Hz) |
