The bass driver assembly employs a hugely powerful magnetic system and massive voice coil to deliver the immense power and scale required for serious home theatre or music reproduction.

A 600 Watt Class-D amplifier (Hypex manufactured) is perfectly matched to a high current switching power supply to ensure continuous delivery of high sound pressure levels, whilst accurately reproducing peak transients. A powerful DSP has been employed to deliver the best performance and filter characteristics whilst running the unique APC system. The APC (Automatic Position Correction) system has been designed by Monitor Audio to automatically correct for different types of rooms. It uses a microphone and test tones to calculate detrimental room modes and automatically correct frequency response, optimising it for the room and position. This ensures the user can enjoy the subwoofer without the restrictions of positioning. A sophisticated 32bit micro-controller, monitoring the sound levels thousands of times per second, ensures the woofer delivers the best possible performance.

Settings adjustment is provided by the innovative controller mounted on the cabinet top panel, or by using Monitor Audio’s proprietary ‘SubConnect’ software. The settings provide four fully configurable user pre-sets per input, including modes for; Flat/Music/Movie and Impact equaliser settings. Fine-tuning can be made by adjusting the frequency, slope, trim and equaliser filters for each pre-set. The Night Mode actively reduces the dynamic range of louder sections according to the level the listener desires.

Key Features

• Smaller cabinet than before, with a higher output
• Three driver subwoofer system featuring two 20 cm ABR’s (Auxiliary Bass Radiators)
• Punchy bass below 20 Hz
• Ultra-long throw 12” driver featuring;   – Dished C-CAM cone   – Rigid die-cast chassis   – Black pole and motor plates for effective heat radiation   – Larger 75 mm diameter voice coil – black anodised to radiate more heat away   – Triple suspension for ultimate linearity – ensuring control at high power and excursions
• Powerful 600 Watt Hypex Class-D Amplifier module, with switching power supply – provides instantaneous delivery of high current when required• DSP processing with all control features and crossover performed digitally
• APC (Automatic Position Correction) – in-house developed automatic room set-up feature using microphone for simple system optimization
• Top mounted control panel• USB for connection to SubConnect application, firmware updates and service
• Four pre-set Equaliser mode settings – Flat, Music, Movie, and Impact
• Night Mode – actively reduces dynamic range of louder sections to desired level
• 12 V trigger – provides switching control from AV receiver/ processor or control system
• 3.5 mm microphone input jack for APC – microphone included• Serial Control interface for connection and control by system controller – Serial RS232 (RJ45)
• Wide choice of input and outputs, with professional grade balanced LFE input and buffered output; providing effective noise reduction over long cable runs
• IR remote included – receiver on front panel• 3.5 mm jack IR repeater – when mounted in a cabinet or installed out of sight
• Rigid 25 mm MDF construction with 36 mm front baffle for super rigid 12” driver mounting
• Separate, sealed amplifier compartment with venting for effective heat convection
• Selected premium quality wood veneers, superior piano lacquer and satin white finishes.
