Pro-Ject Phono Box

Today, many amplifiers do not have a specific phono cartridge inputs. The Pro-Ject Phono Box is an ideal affordable solution for connecting a turntable up to your existing system, and it is also capable of working with both Moving Magnet and Moving Coil cartridges.

SKU
PHONOBOX-CONFIG
As low as £99.00

The output of Phono Box can easily be connected with a line-input on your amplifier.

Key Features

  • Metal case shields the electronics from vibrational and electromagnetic interference
  • Optimal channel separation through dual-mono circuitry
  • Special low-noise ICs used
  • Gold plated RCA connection sockets
  • Outboard power supply included
  • Amplification and RIAA equalisation for MM and MC cartridges
  • Phono MM/MC selection switch located at the rear of the unit
  • Small size allows installation close to record player

Phono Box

Input Impedance MM - 47kΩ / 120pF
MC - 100Ω / 120pF
Gain MM - 40dB
MC - 60dB
Output Voltage Typically MM - 300mV @ 1kHz - 3mV
MC - 0.3mV
Maximum Output 9.5V (1kHz)
Noise Floor MM - 86dB (94dB - A weighted)
MC - 68dB (75dB - A weighted)
THD MM - 0.01%
MC - 0.05%
RIAA Equalisation Curve Accuracy 20Hz - 20kHz / max. 0.5dB
Input 1 Pair RCA Phono Sockets
Line Level Output 1 Pair RCA Phono Sockets
Outboard Power Supply 18V/500mA DC
PSU 18V/500mA DC
Dimensions (W x H x D) 103 x 36 x 104mm
103 x 36 x 115mm (Incl. Sockets)
Weight 570G (Without PSU)
