Amplifiers |
Fifteen Class-D digital amplifiers perfectly tuned to the unique acoustic architecture. |
Tweeters |
Seven precisely angled silk-dome tweeters create crisp high frequencies and clear dialogue. Two of these fire upward, creating dedicated height channels for spatial audio. |
Mid-woofers |
Six midwoofers ensure faithful playback of mid-range frequencies. |
Woofers |
Sound Motion™, a four-motor, dual-membrane woofer, delivers exceptional bass in a revolutionary flat, compact design. |
Microphones |
The far-field microphone array uses advanced beamforming and multichannel echo cancellation for quick and accurate voice control and Trueplay tuning. Disconnect by toggling off the mic switch. |
Adjustable EQ |
Use the Sonos app to adjust bass, treble, and loudness. |
Trueplay |
This software measures the acoustics of the room then fine-tunes the EQ. Compatible with iOS and Android devices. |
Speech Enhancement |
Choose your preferred level of dialogue clarity in the Sonos app. |
Night Sound |
Turn this setting on in the Sonos app to reduce the intensity of loud sounds and increase the level of quieter sounds. |
Home Cinema audio formats |
Stereo PCM, Dolby Digital, Dolby Digital Plus, Dolby Atmos (Dolby Digital Plus), Dolby Atmos*, Dolby TrueHD*, Dolby Atmos (True HD)*, Multichannel PCM*, Dolby Multichannel PCM*, DTS Digital Surround**
The Sonos app's Now Playing screen will display what type of audio is being decoded.
*HDMI6 eARC connection required.
**This is not an indication of a licensed decoder.
|
Dolby Atmos Music |
Requires compatible content. |
TV Audio Swap |
Swap TV audio between the soundbar and Sonos Ace headphones. |
Dimensions |
Height: 2.95 in (75 mm)
Width: 46.38 in (1,178 mm)
Depth: 4.35 in (110.6 mm)
|
Weight |
13.01 lbs (5.9 kg) |
Colours |
Black, White |
Finish |
Matte |
Mounting |
M5 x 0.8mm thread pitch L6.5mm |
Controls |
Use the capacitive touch controls to play, pause, skip, replay, adjust the volume, turn off voice assistants, and group or ungroup Sonos products. |
Bluetooth Button |
Press to pair with a Bluetooth device. |
Mic switch |
Toggle off the switch on the back of the product to disconnect power to the microphones. |
LEDs |
Lights on the product indicate connection, mute status, microphone activation and errors. |
WiFi |
Compatible with WiFi 6. Connect to WiFi with any 802.11a/b/g/n/ac/ax 2.4 GHz/5 GHz broadcast-capable router. |
HDMI eARC |
Connect to your TV's HDMI eARC/ARC port with the included HDMI cable. |
Optical |
Optical audio adapter sold separately. |
Bluetooth |
Bluetooth 5.3 supports audio streaming from any Bluetooth-enabled device. |
Voltage |
100-240V 50/60Hz internal power supply |
CPU |
Quad Core
4xA55 1.9GHz
|
Memory |
2GB SDRAM
8GB NV
|
Voice |
Works with Sonos Voice Control and Amazon Alexa. Availability of services varies by language and country. |
Apple AirPlay 2 |
Works with AirPlay 2 on Apple devices iOS 11.4 and higher on WiFi |
TV Compatibility |
Not compatible with CCFL-backlit TVs (manufactured 2004-2012) |
WiFi |
Internet connection |
Power Source |
Nearby electrical outlet |
Sonos app |
The latest generation of the Sonos app running on a compatible device |
Amplifiers |
Dual Class-D digital amplifiers perfectly tuned to the subwoofer's unique acoustic architecture. |
Frequency Response |
As low as 25 Hz |
Woofers |
Dual 5" x 8" elliptical woofers face inward for a force-cancelling effect that virtually eliminates distortion. |
Microphones |
The far-field microphone array uses advanced beamforming and multichannel echo cancellation for quick and accurate voice control and Trueplay tuning. Disconnect by toggling off the mic switch. |
EQ |
Audio settings automatically equalise to balance Sub 4 and the paired Sonos speaker(s). Use the Sonos app to adjust bass, treble, and loudness. |
Architecture |
Ported cabinet enhances bass response. |
Trueplay |
This software measures the acoustics of the room then fine-tunes your Sonos system. |
Dimensions |
Height: 15.31 in (389 mm)
Width: 15.83 in (402 mm)
Depth: 6.22 in (158 mm)
|
Weight |
25.99 lbs (11.79 kg) |
Colours |
Black, White |
Finish |
Matte |
Join Button |
Press once to add Sub 4 to your system during setup. |
WiFi |
Connects to any 802.11a/b/g/n/ac/ax 2.4/5 GHz broadcast-capable router. |
Ethernet |
10/100 port for hardwiring to your router |
Voltage |
100-240V 50/60Hz internal power supply |
CPU |
Quad Core
4xA55 1.9GHz
|
Memory |
512 MB DDR4
4GB eMMC
|
Operating Temperature |
32°F to 104°F
(0°C to 40°C)
|
WiFi |
Internet connection |
Power Source |
Nearby electrical outlet |
Sonos app |
The latest generation of the Sonos app running on a compatible device |
Amplifiers |
Six class-D digital amplifiers precision-tuned for the speaker's unique acoustic architecture power your sound experience. |
Tweeters |
Four tweeters ensure faithful playback of high and mid-range frequencies. The forward-firing mid tweeter provides a smooth centre image while two side-firing mid tweeters create stereo separation. Loaded into a directional horn, the upward-firing tweeter reflects sound off the ceiling when playing Dolby Atmos content. |
Woofers |
Two woofers maximise low-end output and are angled left and right to support stereo playback. |
Microphones |
The far-field microphone array uses advanced beamforming and multichannel echo cancellation for quick and accurate voice control and Trueplay tuning. Disconnect by toggling off the mic switch. |
Adjustable EQ |
Use the Sonos app to adjust bass, treble and loudness. |
Trueplay |
This software measures the acoustics of the room then fine-tunes the EQ. Compatible with iOS and Android devices. |
Colours |
Black, White |
Finish |
Matte |
Bluetooth Button |
Press to pair with a Bluetooth device. |
Controls |
Use the buttons to play, pause, skip, replay, adjust the volume, turn off the microphones, manually switch to Bluetooth, and more. |
LEDs |
Lights on the product indicate connection, charge status, mute status, microphone activation, and errors. |
Mic Switch |
Toggle off this switch on the back of the product to disconnect all power to the microphone hardware. |
Dimensions |
Height: 6.30 in (160 mm)
Width: 10.24 in (260 mm)
Depth: 7.28 in (185 mm)
|
Weight |
9.85 lb (4.47 kg) |
WiFi |
Compatible with WiFi 6. Connect to WiFi with any 802.11a/b/g/n/ac/ax 2.4 GHz/5 GHz broadcast-capable router. |
Bluetooth |
Bluetooth 5.0 supports audio streaming from any Bluetooth-enabled device. |
USB-C Port |
15W, 5V/3A |
Voltage |
100-240V 50/60Hz internal power supply |
CPU |
Quad Core, 1.4 GHz A-53 |
Memory |
1GB SDRAM, 4GB NV |
Apple AirPlay 2 |
Works with AirPlay 2 on Apple devices iOS 11.4 and higher on WiFi |
Voice |
Works with Amazon Alexa and Google Assistant on WiFi |
WiFi |
Internet connection |
Power Source |
Nearby electrical outlet |
Sonos app |
The latest generation of the Sonos app running on a compatible device |
